What Size Inverter Do You Need for a 100kW Solar Array? (2026 Sizing Rules)

If you are sizing an inverter for a 100kW DC solar array, the short answer is that you do not need a 100kW inverter. Based on my experience overseeing commercial installations across the US for the past eight years, the optimal inverter size for a standard 100kW PV system typically falls between 77kW and 83kW. This is determined by the inverter loading ratio (ILR), also known as the DC-to-AC ratio. This article will walk you through exactly how to calculate that number, why the rules changed with 2026 equipment, and when you might actually need a larger unit.

My Role: Why This Advice Comes from Real Installations

I am a senior solar design engineer and project lead for a mid-sized commercial installer based in California. For the last eight years, I have personally overseen the procurement, design, and commissioning of over 150 commercial and industrial solar projects ranging from 30kW to 1.2MW. My conclusions on inverter sizing come directly from reviewing production data, troubleshooting clipping losses, and analyzing financial payback for clients across different climate zones—from the high desert heat to the Pacific Northwest.

Not Sure Where to Start? The 3-Step Sizing Check

If you just want to verify your inverter size without reading the technical deep-dive, run through this quick checklist based on current NEC guidelines and 2026 manufacturer data.

• Check the DC-to-AC Ratio: Divide your DC array size (100kW) by the inverter's AC output. For most of the US, you want this number between 1.20 and 1.30.
• Look at the Inverter's Input Voltage: Ensure the inverter's MPPT voltage range can handle your string configuration, especially the cold-weather voltage rise.
• Consider Your Specific Tariff: If you are in a utility territory with no time-of-use rates or high demand charges, a slightly higher ratio (1.30) often makes the most sense.

Why a 100kW Solar Array Usually Doesn't Use a 100kW Inverter

The most common mistake I see from new system designers is trying to match inverter AC power exactly to the DC array size. In practice, almost every commercial system built today is "inverter-clipped" by design. This is because a solar panel almost never produces its rated nameplate power (STC) in the real world. Factors like heat, soiling, and system degradation mean your 100kW array will likely produce between 80kW and 90kW AC during peak sun, even on a good day .

By oversizing the DC array relative to the inverter—a concept called "overpaneling"—you capture more energy during the early morning, late afternoon, and cloudy days. The inverter hits its peak capacity for a few hours around noon but runs efficiently for longer. This provides a better return on investment than buying a larger, more expensive inverter just to handle those few peak hours.

How to Calculate the Exact Inverter Size for Your 100kW Project

The method we use isn't a guess; it's a financial and engineering calculation based on the Inverter Loading Ratio (ILR). To find your specific inverter size, you use this formula: Inverter AC Size = Total DC STC Size / Target ILR. For a 100kW system, the decision lies in picking the right ILR number.

When to Use an ILR of 1.20 (The 83kW Inverter)

We typically use an ILR closer to 1.20 for specific scenarios. If your site has perfect south-facing exposure with zero shading, very cool average temperatures (which boosts panel voltage), and you're in a high Time-of-Use (TOU) rate area where production at the absolute peak of the day is extremely valuable, you might want a slightly larger inverter to shave off the top of the clipping curve. In this case, you would pair your 100kW array with an 83kW inverter (100 / 1.20 = 83.3).

When to Use an ILR of 1.30 (The 77kW Inverter)

The vast majority of our commercial flat-roof installations use an ILR around 1.25 to 1.30. If your array faces East/West, has a shallow tilt, or is in a hot climate like Phoenix or Texas, you will almost never see a full 100kW DC punch. Clipping losses are minimal, but the extended production curve is significant. Here, a 77kW inverter is the right choice (100 / 1.30 = 76.9). Most major manufacturers like SolarEdge and Growatt offer commercial inverters in this exact power class, such as the 100kW-rated optimizers paired with a 76.8kW inverter .

What About Hybrid Systems? The 100kW Inverter Exception

There is one major exception to the "downsize the inverter" rule: when you are installing a hybrid system with battery storage. If your goal is to use that 100kW solar array to charge batteries AND run a large load simultaneously, or to provide backup power, the rules change completely .

For example, the Growatt WIT 100K-HU-US is a true 100kW hybrid inverter. In these cases, you need the full 100kW AC capacity not just for the solar, but to pull power from the batteries to support large commercial loads. If your project requires "black start" capability or islanding, you must size the inverter to handle the load, not just the solar production. We recently installed a system with a 100kW inverter paired with a 130kW DC array to ensure we had enough battery charging capacity during winter months .

Technical Compatibility: Matching Your 100kW Array to the Inverter

Beyond the power rating, you must ensure the inverter you select can handle the electrical characteristics of your specific modules. Here are the non-negotiable technical specs based on current UL1741 equipment available in the US.

What Size Inverter Do You Need for a 100kW Solar Array? (2026 Sizing Rules)

1. Maximum Input Voltage (Voc): This is the most common killer of designs. When you calculate the string voltage on a cold winter morning, it must not exceed the inverter's absolute max DC voltage. For most 100kW-class inverters sold in the US today, that limit is 1000V or 1500V. For instance, the SolarEdge SE100KUS has a max of 1000V, while utility-scale string inverters are moving toward 1500V .

What Size Inverter Do You Need for a 100kW Solar Array? (2026 Sizing Rules)

2. MPPT Voltage Range: Your array's operating voltage must stay within the inverter's MPPT window. Most commercial inverters, like the Yaskawa Solectria PVI-100TL, have a wide range (e.g., 200V to 1000V), but you need to check that your string configuration lands in the "sweet spot" around 600V-800V for maximum efficiency .

3. US Grid Compliance (480V): Almost every 100kW-scale commercial project in the US ties into a 480V three-phase grid. You must ensure your inverter is specifically listed for that. Models like the CSI-100K-T480GL02-U are explicitly designed for that 480V output, while others might be configured for 208V or 600V grids .

Common Sizing Mistakes We See on Job Sites

Over the years, I've had to re-engineer a few projects that got the sizing wrong. To help you avoid the same fate, here are two clear negative scenarios.

The "Bigger is Better" Trap: Installing a 100kW inverter on a 100kW DC array is usually a waste of capital. You pay a premium for a larger chassis, larger disconnects, and higher capacity that you might only use for 50 hours a year. In the current market, that extra capacity could cost you $5,000 to $10,000 more for a negligible gain in annual production.

When a 1.40 ILR Fails: Going too high on the ratio (e.g., a 71kW inverter on a 100kW array) can void warranties and lead to excessive clipping where you actually lose money. While some manufacturers like SolarEdge allow up to 150% DC oversizing, this requires very specific environmental conditions and approval . In most urban environments with standard modules, a 1.40 ratio will clip so hard that you lose the "shoulder" production you were trying to gain.

Frequently Asked Questions on 100kW Inverter Sizing

Can I use a 100kW string inverter for a 100kW DC array?

Yes, you physically can, but it's rarely the most cost-effective design. You will leave significant "free" energy on the table during non-peak hours compared to an oversized DC array. It only makes financial sense if you are interconnection-limited and cannot feed more than 100kW AC back to the grid.

What is the standard DC-to-AC ratio for commercial solar in 2026?

The industry standard has settled between 1.20 and 1.35. For a fixed-tilt commercial rooftop in 2026, we typically design for a 1.25 ratio. This is baked into the assumptions of most financial models used by solar investors today because it optimizes the Levelized Cost of Energy (LCOE) .

Does module efficiency affect inverter sizing?

What Size Inverter Do You Need for a 100kW Solar Array? (2026 Sizing Rules)

Absolutely. If you are using high-efficiency bifacial modules (like a 500W+ panel), your array will produce more power earlier and later in the day. This actually strengthens the case for a slightly higher DC-to-AC ratio (like 1.30) because the production curve is fatter, and the inverter will spend more time at its full rated capacity.

Do I need a transformer with a 100kW inverter?

Most modern 100kW commercial inverters are transformerless and tie directly into the 480V grid. However, if you have an older site with a 208V service, you will either need a transformer on the output or choose a specific 208V model, which are less common at this scale .

Making the Final Call: A Practical Summary

Choosing the right inverter for your 100kW solar project comes down to three variables: your site's irradiance, your utility rate structure, and your long-term energy goals. If you are a business owner looking to offset standard usage, a 77kW to 83kW string inverter (with an ILR of 1.20-1.30) is your best bet. Look for certified models on the CEC list, such as the Solis-100K-5G-US or the CSI-100K-T480GL02-U, to ensure you qualify for rebates and grid interconnection .

What Size Inverter Do You Need for a 100kW Solar Array? (2026 Sizing Rules)

If, however, your goal includes full-site backup or heavy battery cycling, you need to step up to a true 100kW hybrid unit like the Growatt WIT series. For everyone else, remember the golden rule of commercial solar in 2026: design for the other 18 hours of the day, not just the noon sun.

One last thought: Don't let perfect be the enemy of good. A system designed with a 1.25 DC-to-AC ratio will outperform a perfectly matched 1.00 system in almost every US market.
